Chumba frame VF2 new S size blue and white.

Frame Specifications
------------------------

# Accepts 120 - 150mm forks
# 5 inches of rear wheel travel
# Made from 7 series Aluminum
# Colors available include Anodized Jet Black, Anodized Blue, White, and Candy Metallic Red.
# Equipped with a Fox RP23 or DHX Air (upcharge) 7.875x2.0
# MSRP $1849 (Frame only)
# Frame Weight 5.3 lbs without shock (Medium)
# Available in XtraSmall(4'11" - 5'4") Small(5'5"-5'9"), Medium(5'8"-6'0"), and Large(6'1"-6'3") sizes*
* Please note that these sizing recommendations are only suggestions and you should be professionally fitted by your local bike shop.

-------------------------------------------------------------------------------------------------------------------
Production features
-----------------------

# Custom made hydrofromed, butted top tube and flared manipulated down tube
# Full carbon fiber rear end for weight savings and compliancy
# Anodized 7 series aluminum hardware.
# Center of mass technology for a centrally balanced chassis.
# Proprietary inverted extra wide bottom bracket shell for improved rigidity.
# Race and trail proven geometry refined over a decade.
# Wider diameter high quality Enduro bearings for smooth, durable, and reliable suspension action.
# Bead blasted anodized finish.
# Neutral braking: CHUMBA frames are active under braking forces to ensure excellent traction throughout all terrain during your descent.
# Efficient pedaling: Axle paths and shock rates configured to eliminate pedal bob and squat - ensuring pedaling power hits the ground.
# Minimal chain growth eliminates pedal feedback.

-----------------------------------------------------------------------------------------------------------------
Geometry
--------
Frame Size X-Small Small Medium Large
Top Tube Length 21.75" 22.5" 23.5" 24"
Head Tube Angle 68 68 68 68
Head Tube Length 3.5" 4.5" 5.0" 5.5"
Head Tube Diameter 1 1/8" 1 1/8" 1 1/8" 1 1/8"
Seat Tube Angle 72.5 73 73 73
Seat Post Diameter 31.6mm 31.6mm 31.6mm 31.6mm
Seat Tube Center-to-Top 14.3" 16.8" 19" 21"
Seat Tube Center-to-Center 11.6" 13.2" 14.5" 16.4"
Chainstay Length 16.75" 16.75" 16.75" 16.75"
Wheelbase 41.7" 42.5" 43" 44"
Bottom Bracket Height 12.25" 13.5" 13.5" 13.5"
Bottom Bracket Width 73mm 73mm 73mm 73mm
Disc Brake Mount I.S. I.S. I.S. I.S.
Travel 5" 5" 5" 5"
* Geometry measured using 140mm fork, except for size X-Small, which was measured using a 120mm fork.


------------------------------------------------------------------------------------------------------------
